Toyota 4Runner III (1995-2003) off on int Wiring diagram
This page shows the only wiring diagram for the component.off on int, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off on int (1 of 1)
4 4 (W/ DRL) (W/O DRL)
5 3 (W/ DRL) (W/O DRL)
9 3 10 13 8 WIP POWER ECU-IG WMTR GND
BACK DOOR ECU (ON LEFT SIDE OF BACK DOOR)
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BODY ECU
CENTER J/B (BEHIND LEFT SIDE OF DASH, TO RIGHT OF STEERING COLUMN)
COMBINATION SWITCH
DRIVER SIDE J/B (ON LOWER LEFT SIDE OF DASH)
ECU-IG FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FURTHEST POSITION
FUSE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IG POWER ECU-B
J/C 4 (LEFT SIDE OF DASH)
J/C 9 (RIGHT SIDE OF DASH)
LT GRN WIRE
MPX-B FUSE
OFF INT
OFF ON INT
PNK WIRE
POWER FUSE
R/W INT R/W ON ECU-B
REAR WIPER MOTOR (ON TOP CENTER OF BACK DOOR)
REAR WIPER/ WASHER SWITCH
RETURN POSITION
STOP
VIO/WHT WIRE
WASH
WASH WASH
WASHER MOTOR (ON RIGHT SIDE INNER FENDER PANEL)
WHT/BLK WIRE
WIP+ WIP- GND
WIPER FUSE
YEL WIRE
Go to component -> Rear washer/wiper circuit -> OFF ON INT
