Toyota 4Runner III (1995-2003) left front door unlock detection switch Wiring diagram
This page shows the only wiring diagram for the component.left front door unlock detection switch, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door unlock detection switch (1 of 1)
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
CLOCK
COMBINATION METER
CRUISE CONTROL SWITCH (COMBINATION SWITCH)
EFI RELAY
ENGINE HOOD COURTESY SWITCH
FRONT, REAR WIPER, WASHER SWITCH
GLOVE BOX LIGHT CIGARETTE LIGHTER
J/C 1, 2 (LEFT INNER FENDER PANEL, FRONT OF STRUT TOWER)
J/C 4 (LEFT SIDE OF DASH)
LEFT FRONT DOOR LOCK CONTROL SWITCH LEFT FRONT DOOR KEY LOCK, UNLOCK SWITCH
LEFT FRONT DOOR UNLOCK DETECTION SWITCH
LEFT FRONT FOG LIGHT RIGHT FRONT FOG LIGHT
LEFT FRONT PARKING LIGHT
LEFT FRONT POWER OUTLET
LEFT FRONT TURN SIGNAL LIGHT
LEFT MIRROR HEATER
MOON ROOF CONTROL RELAY, SWITCH
POWER OUTLET RELAY STARTER RELAY HEATER RELAY
POWER WINDOW MASTER SWITCH
REAR WINDOW DEFOGGER SWITCH UNLOCK WARNING SWITCH
RIGHT FRONT BUCKLE SWITCH REAR POWER OUTLET VSC ACTUATOR
RIGHT FRONT PARKING LIGHT
RIGHT FRONT POWER OUTLET
TO CENTER J/B
TO DATA LINK CONNECTOR 3 (DIAGRAM 3 OF 3)
TO JUNCTION CONNECTOR 9 (DIAGRAM 3 OF 3)
VSC ACTUATOR
VSC ECU
W/ ANTI- THEFT
W/ POWER WINDOWS
W/O POWER WINDOWS
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 3) -> LEFT FRONT DOOR UNLOCK DETECTION SWITCH
