Toyota 4Runner III (1995-2003) left front door speaker right front door speaker Wiring diagram
This page shows the only wiring diagram for the component.left front door speaker right front door speaker, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door speaker right front door speaker (1 of 1)
1 LT
2 PNK WIRE
AUTO ANTENNA
BLK WIRE
BLU WIRE
BRN WIRE
CENTER J/B (LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
DOME FUSE
DRIVER SIDE J/B (LOWER LEFT SIDE OF DASH)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FR+ FL+ ANT ILL-
FUSE
GND BEEP
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
ILL AMP+
LEFT FRONT DOOR SPEAKER RIGHT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
MUTE +B
PNK WIRE
RADIO, PLAYER
RED WIRE
RIGHT REAR DOOR SPEAKER
RL RR
STEREO COMPONENT AMPLIFIER
VIO WIRE
W/ 6 SPEAKERS W/ 6 SPEAKERS
WHT WIRE
YEL WIRE
Go to component -> Radio circuits, with separate amplifier -> LEFT FRONT DOOR SPEAKER RIGHT FRONT DOOR SPEAKER
