Toyota 4Runner III (1995-2003) high low flash Wiring diagram
This page shows the only wiring diagram for the component.high low flash, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high low flash (1 of 1)
BATTERY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BODY ECU (ON DRIVER SIDE J/B)
COMBINATION METER
COMBINATION SWITCH
DIMMER SWITCH
DRIVER SIDE J/B (ON LOWER LEFT SIDE OF DASH)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT, ON INNER FENDER PANEL)
GAUGE FUSE
GRN WIRE
HEAD RELAY
HIGH BEAM INDICATOR
HIGH LOW FLASH
HOT IN ON OR START
HRY
J/C 3 (BEHIND LEFT SIDE OF DASH, ON TOP)
J/C 4 (BEHIND LEFT SIDE OF DASH, ON TOP)
LEFT FRONT DOOR COURTESY SWITCH
LEFT HEAD FUSE
LEFT HEADLIGHT
LIGHT CONTROL SWITCH
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEAD FUSE
RIGHT HEADLIGHT
SOLID STATE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl -> HIGH LOW FLASH
