Toyota 4Runner III (1995-2003) engine room r/b (left side of engine compt, on inner Wiring diagram
This page shows the only wiring diagram for the component.engine room r/b (left side of engine compt, on inner, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine room r/b (left side of engine compt, on inner (1 of 1)
ALT FUSE
ALT-S FUSE FENDER PANEL)
BATTERY
BATTERY GROUND
BLK WIRE
BLU WIRE
CHARGE WARNING LIGHT
COMBINATION METER
DRIVER'S SIDE J/B (ON LOWER LEFT SIDE OF DASH)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT, ON INNER
GAUGE FUSE
GENERATOR
GRN WIRE
GRY WIRE
HOT IN ON OR START
IGN FUSE
J/C 1/ J/C 2 (ON LEFT INNER FENDER PANEL)
NCA WIRE
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Charging circuit -> ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT, ON INNER
