Toyota 4Runner III (1995-2003) back window limit switch Wiring diagrams
This page contains all the electrical diagrams for the component. back window limit switch, in which he is found in the car Toyota 4Runner III (1995-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram back window limit switch (1 of 2)
1 3 2 18 POWER IG ECU-B
BACK DOOR COURTESY SWITCH
BACK DOOR ECU (ON LEFT SIDE OF BACK DOOR)
BACK DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH
BACK WINDOW LIMIT SWITCH
BACK WINDOW MOTOR
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY ECU
BRN/WHT WIRE
CENTER J/B
CENTER J/B (BEHIND LEFT SIDE OF DASH, TO RIGHT OF STEERING COLUMN)
CLSM
DCTY
DRIVER SIDE J/B (ON LOWER LEFT SIDE OF DASH)
ECU B+
ECU-IG
ECU-IG FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT, ON INNER FENDER PANEL)
FUSE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
J/C 10, J/C 11 (AT RIGHT KICK PANEL)
J/C 4 (LEFT SIDE OF DASH)
J/C 6 (BEHIND LEFT SIDE OF DASH)
J/C 9 (RIGHT SIDE OF DASH)
KEYLESS BUZZER
LEFT FRONT
LEFT FRONT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT FRONT DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH
LEFT REAR
LEFT REAR DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH
LMTW
LOCK
LSWB
LSWD
LSWP
LSWR
LT GRN WIRE
MPX-B FUSE
OPNM
PCTY
PNK/BLK WIRE
PNK/GRN WIRE
POWER
POWER FUSE
RCTY
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT
RIGHT FRONT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT FRONT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH
RIGHT REAR
RIGHT REAR DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH
TRY
UNLK
UNLOCK WARNING SWITCH
VIO/WHT WIRE
W/ ANTI- THEFT
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power door lock circuit, with keyless entry -> BACK WINDOW LIMIT SWITCH
Wiring diagram back window limit switch (2 of 2)
BACK DOOR ECU (ON LEFT SIDE OF BACK DOOR)
BACK WINDOW CONTROL SWITCH
BACK WINDOW LIMIT SWITCH
BACK WINDOW LOCK SWITCH
BACK WINDOW MOTOR (IN CENTER OF BACK DOOR)
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY ECU
CENTER J/B (BEHIND LEFT SIDE OF DASH, TO RIGHT OF STEERING COLUMN)
CLS
CLSM
DIODE (BACK WINDOW) (TOP RIGHT SIDE OF DASH)
DRIVER SIDE J/B (ON LOWER LEFT SIDE OF DASH)
ECU B+
ECU-IG
ECU-IG FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPARTMENT)
FRONT, REAR WINDOW CIRCUIT
FUSE
GND DOWN
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN
HOT IN ON OR START
J/C 5 (BEHIND LEFT SIDE OF DASH)
J/C 9 (BEHIND TOP RIGHT SIDE OF DASH)
LMTW
MPX-B FUSE
OPN
OPNM
POWER
POWER FUSE
PWR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
TAILGATE CONTROL SWITCH
VIO/WHT WIRE
W/O POWER WINDOW
WHT/BLK WIRE
WIPER FUSE
YEL WIRE
Go to component -> Tailgate power window circuit -> BACK WINDOW LIMIT SWITCH
