Toyota 4Runner III (1995-2003) +b code rxck txct gnd 2 3 4 5 Wiring diagram
This page shows the only wiring diagram for the component.+b code rxck txct gnd 2 3 4 5, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +b code rxck txct gnd 2 3 4 5 (1 of 1)
+B CODE RXCK TXCT GND 2 3 4 5
10 5 18 19 11 12 EOM CODE RXCK TXCT KSW IMLD
15 16 4 1 IGSW BATT MREL +B
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CENTER J/B (BEHIND LEFT SIDE OF DASH, TO RIGHT OF STEERING COLUMN)
DRIVER SIDE J/B (ON LOWER LEFT SIDE OF DASH) IGN FUSE
EFI FUSE
EFI RELAY
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT, ON INNER FENDER PANEL)
GRY/BLK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ON OR START
J/C 1, J/C 2 (LEFT INNER FENDER PANEL)
J/C 4 (LEFT SIDE OF DASH)
J/C 6 (BEHIND LEFT SIDE OF DASH)
J/C 7, J/C 8 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 9 (RIGHT SIDE OF DASH)
PNK/BLK WIRE
RED/BLK WIRE
SECURITY INDICATOR LIGHT (CENTER CLUSTER SWITCH)
TRANSPONDER KEY AMPLIFIER (LEFT SIDE OF DASH, AT STEERING COLUMN)
UNLOCK WARNING SWITCH
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL/RED WIRE
Go to component -> Immobilizer circuit -> +B CODE RXCK TXCT GND 2 3 4 5
