Toyota 4Runner III (1995-2003) ant amp Wiring diagram
This page shows the only wiring diagram for the component.ant amp, which is found in the car Toyota 4Runner III (1995-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ant amp (1 of 1)
AMP
ANT
ANT AMP
ANTA
ANTB
AUTO ANTENNA CONTROL RELAY (BEHIND CENTER OF DASH, FRONT OF CONSOLE) IG
AUTO ANTENNA MOTOR (RIGHT FRONT INNER FENDER)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CENTER J/B (LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
DRIVER SIDE J/B (LEFT SIDE OF DASH)
DRIVER SIDE J/B (LOWER LEFT SIDE OF DASH)
ECU-IG FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) DOME FUSE
FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
J/C 4 (BEHIND LEFT SIDE OF DASH)
PNK WIRE
PNK/BLU WIRE
RADIO, PLAYER
STEREO COMPONENT AMPLIFIER (BEHIND CENTER OF DASH)
W/ BUILT-IN AMPLIFIER
W/ SEPARATE AMPLIFIER
WHT WIRE
YEL WIRE
Go to component -> Power antenna circuit -> ANT AMP
