Trunk, tailgate, fuel door circuit for Suzuki XL7 II (2006-2009)

BATT MAIN 2 FUSE 50 BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) CLASS 2 (BCM) CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM DK GRN WIRE GMLAN SERIAL DATA GROUND GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT IGN INSTRUMENT PANEL CLUSTER (IPC) L/GATE FUSE 4 LIFTGATE AJAR SW LIFTGATE IND LIFTGATE LATCH RELAY COIL CONTROL LIFTGATE LATCH RELAY SUPPLY VOLT LIFTGATE PCB RELAY LIFTGATE RELEASE ACTUATOR LIFTGATE SWITCH LOGIC LT BLU WIRE PNK/BLK WIRE REAR CLOSURE HANDLE SWITCH OPEN SIGNAL RED WIRE SIDE OF RADIO) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WIPER/ WASHER SYSTEM YEL WIRE
