Radio circuit, premium for Suzuki XL7 II (2006-2009)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 LH AUDIO SIG (+) RH AUDIO SIG (+) 367 368 SATELLITE RADIO CIRCUIT 5748 372 388 SATELLITE RADIO CIRCUIT ANTENNA BARE BARE 15 16 BARE BATT POS VOL BCM FUSE 20 BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) BRN WIRE BRN/WHT WIRE CASE GND CIRCUIT COAX COAX ANTENNA COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (BELOW BRAKE MASTER CYLINDER) ENABLE GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) INFO INTERIOR LIGHTS SYSTEM 1551 118 1985 LOW SERIAL DATA LR SPEAKER OUT (-) RR SPEAKER OUT (-) LT BLU WIRE LT GRN WIRE MUTE MUTE LH AUDIO SIG (-) RH AUDIO SIG (-) NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK/BLK WIRE PPL PPL BARE PPL STEERING WHEEL CTRL SPLY VOL PPL TRANSMISSIONS SYSTEM PPL/WHT WIRE RADIO RDO FUSE 17 RED/WHT WIRE RIGHT STEERING WHEEL CONTROL SWITCH SEEK DOWN SEEK UP SOURCE STEERING WHEEL CTRL SIG TAN WIRE TAN/WHT WIRE VIDEO DISPLAY VIDEO SYSTEM VOL DOWN VOL UP VSS W/ DVD PLAYER WHT WIRE WHT/BLK WIRE YEL WIRE

1 2 3 4 5 6 7 8 COIL 2 OUT (-) COIL 2 OUT (+) COIL 1 OUT (-) COIL 1 OUT (+) GND 1 2 BARE AMP FUSE 12 AMPLIFIER (IN RIGHT REAR QUARTER, BEHIND SUBWOOFER) BARE BATT POS VOL BLK WIRE BRN WIRE BRN/WHT WIRE CASE GND CELLULAR TELEPHONE MICROPHONE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LEFT FRONT SPEAKER LEFT FRONT SPEAKER (TWEETER) LEFT REAR SPEAKER LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE RADIO AUDIO MUTE SIG RED/WHT WIRE RF SPEAKER OUT (-) RF SPEAKER OUT (+) LF SPEAKER OUT (+) LF SPEAKER OUT (-) RIGHT FRONT SPEAKER (TWEETER) RIGHT REAR SPEAKER RIGHT FRONT SPEAKER SUBWOOFER SPEAKER TAN WIRE WHT WIRE YEL WIRE
