Back-up lamps circuit for Suzuki XL7 II (2006-2009)
Back-up lamps circuit
3 1 BAT POS VOLT GROUND
BACK-UP LP SUPPLY VOLT
BCM FUSE 20
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
LEFT BACK-UP LAMP
LOGIC INSIDE REARVIEW MIRROR (IF EQUIPPED)
LT GRN WIRE
RED/WHT WIRE
RIGHT BACK-UP LAMP
