Car Wiring Diagrams for Defoggers circuit for Suzuki XL7 II (2006-2009)

BLK WIRE DEFOGGER INDICATOR HOT AT ALL TIMES HVAC CONTROL MODULE (AT CENTER OF DASH) I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LOGIC PPL REAR DEFOG FUSE REAR DEFOG RELAY REAR DEFOGGER GRID REAR DEFOGGER SWITCH RED/BLK WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) WHT WIRE
