Suzuki XL7 II (2006-2009) pnk sw sig mode dr ctrl temp ctrl Wiring diagram

193 735 1450 DEFOGGER SYSTEM 2145 2615 2214 REAR A/C CIRCUIT 5 VOLT REF 5-VOLT REF SPLY VOLT SPLY VOLT LOW REF 5954 2599 760 REAR A/C CIRCUIT ACTR POS SIG SENS CTRL MODE DR CTRL AMBIENT AIR TEMPERATURE SENSOR (BELOW LF HEADLIGHT, ON BUMPER BAR) AMBIENT LIGHT SENSOR (UPPER LEFT DASH TRIM PANEL) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) BRN WIRE COMPUTER DATA LINES SYSTEM DEF RLY CTRL TEMP SENS SIG GND DIMMING SIG DK BLU WIRE DK GRN WIRE DR CTRL TEMP DR CTRL DR CTRL TEMP DR CTRL LOW REF LOW REF DRV SENS PASS SENS GND SENS SIG EVAPORATOR TEMPERATURE SENSOR (IN ENGINE COMPT, NEXT TO EXPANSION VALVE BLOCK) GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ IGN MAIN RELAY 31 ENERGIZED HVAC CONTROL MODULE (AT CENTER OF DASH) HVAC/RFA FUSE 15 I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) INTERIOR LIGHTS LOW REF LOWER AIR TEMPERATURE SENSOR (ON LOWER LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MODE ACTUATOR (ON LEFT SIDE OF HVAC ASSEMBLY) MTR CTRL MODE MTR CTRL MTR SPD CTRL MTR SPD CTRL MODE DR CTRL TEMP DR CTRL ORG/ WIRE PNK SW SIG MODE DR CTRL TEMP CTRL WIRE PNK WIRE PPL PPL/WHT WIRE REAR A/C CIRCUIT RECIRCULATION ACTUATOR (ON HVAC MODULE) RED/WHT WIRE RIGHT SIDE OF TEMPERATURE ACTUATOR) SENS SIG SENSOR SYSTEM TAN WIRE TAN/BLK WIRE TEMP SENS SIG TEMP SENS SIG DRV SENS SIG PASS SENS SIG TEMPERATURE ACTUATOR (ON HVAC ASSEMBLY) UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) SIR DISPLAY FUSE 25 UPPER AIR TEMPERATURE SENSOR (ON UPPER WHT WIRE YEL WIRE
