Suzuki XL7 II (2006-2009) pass seat belt ind Wiring diagram

ABS IND. AIR BAG IND ANTI-THEFT SYSTEM BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) BRAKE FLUID LEVEL SWITCH BRAKE IND BRAKE WARNING IND CTRL BRN WIRE BRN/WHT WIRE CLASS 2 (PCM) COMPUTER DATA LINES SYSTEM COOLANT TEMPERATURE GAGE CRUISE IND DIC SELECT MENU SW SIG DIC SW SIG DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE DRIVER INFORMATION CENTER (DIC) SWITCH DRIVER INFORMATION CENTER SELECT MENU SWITCH SIGNAL DRIVER INFORMATION CENTER SWITCH SIGNAL DRL IND ENGINE CONTROL MODULE (ECM) (MOUNTED ON TOP OF BATTERY COVER) ENGINE CONTROLS SYSTEM ENGINE OIL PRESSURE (EOP) SWITCH (LEFT SIDE OF ENGINE, ABOUT FOG LAMPS IND FUEL GAGE FUEL PUMP, SENDER ASSEMBLY GROUND HI SPD GMLAN SER DATA - HOT AT ALL TIMES HOT W/ IGN MAIN RELAY 31 ENERGIZED I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) CLSTR FUSE 18 IGN INSTRUMENT PANEL CLUSTER (IPC) KM 000000 TRIP LCD DISPLAY LED DIMMING SIGNAL LEFT TURN IND LOGIC LOW GMLAN SERIAL DATA LOW REF LOW REFERENCE LOW SPD GMLAN SERIAL DATA LT BLU WIRE MALFUNCTION IND LAMP MIL CONTROL OIL LEVEL IND OIL PRESSURE SW SIG ORG/ WIRE PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER) PASS AIR BAG OFF IND CTRL PASS AIR BAG ON IND CTRL PASS SEAT BELT IND PNK PNK WIRE PNK WIRE PPL PPL FUEL LEVEL SENS SIG PPL/WHT WIRE PRIMARY FUEL LEVEL SENSOR RED WIRE RED/WHT WIRE RIGHT TURN IND SEAT BELT IND SECONDARY FUEL LEVEL SENSOR SECURITY IND SIR DISPLAY FUSE 25 SPEEDOMETER STARTER MOTOR SUPPLEMENTAL RESTRAINTS SYSTEM SW SIG PARK BRAKE TACHOMETER TAN WIRE TAN/BLK WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE
