Suzuki XL7 II (2006-2009) front vertical down Wiring diagram
This page shows the only wiring diagram for the component.front vertical down, which is found in the car Suzuki XL7 II (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front vertical down (1 of 1)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR (UNDER DRIVER SEAT)
DRIVER SEAT HORIZONTAL MOTOR (UNDER DRIVER SEAT)
DRIVER SEAT REAR VERTICAL MOTOR (UNDER DRIVER SEAT)
FRONT VERTICAL DOWN
FRONT VERTICAL UP
HORIZONTAL FORWARD
HORIZONTAL REARWARD
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
LT BLU WIRE
POWER SEAT CIRCUIT BREAKER
REAR VERTICAL DOWN
REAR VERTICAL UP
RED WIRE
RED/BLK WIRE
YEL WIRE
Go to component -> Driver seat circuit -> FRONT VERTICAL DOWN
