Suzuki XL7 II (2006-2009) chmsl dimr fuse 22 Wiring diagrams
This page contains all the electrical diagrams for the component. chmsl dimr fuse 22, in which he is found in the car Suzuki XL7 II (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram chmsl dimr fuse 22 (1 of 2)
ACC VOLT
AMBIENT LIGHT SENS SIG HEADLAMP SW ON SIG
ANTI-LOCK BRAKES SYSTEM SHIFT INTERLOCK SYSTEM
BATT POS VOLT INST PANEL LMP SPLY VOLT
BCM FUSE 20
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
BRAKE PEDAL POS SENS SIG LOW REF
BRN WIRE
BRN/WHT WIRE
CHMSL DIMR FUSE 22
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DOOR LOCKS, ANTI-THEFT SYSTEMS
FRONT FOG LMP SW SIG CRUISE CTRL IND DIMMING SIG
FUSE 11
FUSE 23
FUSE 7
GRY WIRE
HEADLAMP SW ON SIG
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM CRUISE CONTROL SYSTEM
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
INT LTS
INTERIOR LIGHTS SYSTEM ANTI-LOCK BRAKES SYSTEM
LT BLU WIRE
LT GRN/BLK WIRE
LT TRN/ SIG
ORG/ WIRE
ORG/BLK WIRE
ORG/WHT WIRE
PARK LMP SW ON SIG
PNK IGN 1 VOLT ENDGATE LATCH RLY COIL CTRL DRL RELAY CTRL WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
RED/WHT WIRE
RT TRN/ SIG
RVC FUSE 42
STARTING/CHARGING SYSTEM
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRACTION CTRL SW SIG KEY CAPTURE/COLUMN LOCK SHIFT POS SIG
TRANSMISSIONS SYSTEM
TRANSMISSIONS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM HEADLIGHTS SYSTEM
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WINDSHIELD WASHER RLY CTRL HEADLAMP HI BEAM RLY CTRL HOOD AJAR SW SIG
WIPER MTR PARK SW SIG
WIPER/WASHER SYSTEM
WIPER/WASHER SYSTEM HEADLIGHTS SYSTEM ANTI-THEFT SYSTEM
YEL WIRE
Go to component -> Body control modules circuit (2 of 2) -> CHMSL DIMR FUSE 22
Wiring diagram chmsl dimr fuse 22 (2 of 2)
1 3 4 5 BAT POS VOLT BAT POS VOLT BAT POS VOLT LAMP SPLY VOLT
15 14 13 5-V REFERENCE LOW REFERENCE PED POS SENS SIG
19 16 15 HAZARD SW SIG RH TURN SW SIG LH TURN SW SIG
5 4 24 1 2 CHMSL SPLY VOLT LAMP SPLY VOLT
AUTO PARK HEAD LIGHT SWITCH
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
BRAKE PEDAL POSITION SENSOR (ON BRAKE PEDAL ASSEMBLY)
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
CHMSL DIMR FUSE 22
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
LAMP SPLY VOLT LAMP SPLY VOLT
LEFT
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/ TURN SIGNAL LAMP LEFT FRONT PARK LAMP
LEFT LICENSE LAMP RIGHT LICENSE LAMP
LEFT REAR PARK/ STOP LAMP
LEFT REAR PARK/ TURN SIGNAL LAMP
LEFT TURN IND
LH PRK/LP FUSE 14 RH PRK/LP FUSE 10
LT BLU WIRE
LT BLU/WHT WIRE
LT TRN/ SIG FUSE 7
MAJ
MIN
NOT USED NOT USED
OFF
ORG/BLK WIRE
PARK LAMP PCB RELAY
PPL
PRK/ LP
RED/WHT WIRE
RIGHT
RIGHT FRONT PARK LAMP RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ TURN SIGNAL LAMP
RIGHT REAR PARK/STOP LAMP
RIGHT REAR PARK/TURN SIGNAL LAMP
RIGHT TURN IND
RT TRN/ SIG FUSE 7
STOP LAMP PCB RELAY
STOP LP FUSE 27
TAN WIRE
TRLR FUSE 35
TURN SIGNAL SWITCH
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> CHMSL DIMR FUSE 22
