Suzuki XL7 II (2006-2009) 5229 5016 rollover sensor left signal right signal Wiring diagram
This page shows the only wiring diagram for the component.5229 5016 rollover sensor left signal right signal, which is found in the car Suzuki XL7 II (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 5229 5016 rollover sensor left signal right signal (1 of 1)
1340 1139 BATT POSITIVE VOLTAGE IGNITION 1 VOLTAGE PNK WIRE
3 4 5 6 7 8 9 10 11 PNK WIRE
5229 5016 ROLLOVER SENSOR LEFT SIGNAL RIGHT SIGNAL
AIR BAG INDICATOR
AIR BAG OFF IND
AIR BAG ON IND
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CASE GROUND
CLASS 2 (SDM)
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGN MAIN RELAY 31 ENERGIZED
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
IGN
IGN 1 VOLT
INFLATABLE RESTRAINT FRONT END SENSOR (RIGHT)
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INSTRUMENT PANEL CLUSTER (IPC)
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER AIR BAG OFF INDICATOR
PASSENGER AIR BAG ON INDICATOR
PNK W/ ROOF SIDE AIR BAG WIRE
PNK WIRE
PPL
RED/WHT WIRE
SHORTING BAR
SIR DISPLAY FUSE 25
SIR FUSE 5 ADS MODULE FUSE 9
TAN WIRE
TAN/ORG WIRE
TAN/WHT WIRE
W/ ROOF SIDE AIR BAG
W/O ROOF SIDE AIR BAG PNK WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> 5229 5016 ROLLOVER SENSOR LEFT SIGNAL RIGHT SIGNAL
