Suzuki XL7 II (2006-2009) 4 3 can bus low can bus high Wiring diagram

14 8 7 6 HIGH DATA BUS (+) HIGH DATA BUS (-) HIGH DATA BUS (-) HIGH DATA BUS (+) 4 3 CAN BUS LOW CAN BUS HIGH 42 55 HIGH DATA BUS (-) HIGH DATA BUS (+) 6 SPEED A/T 9 8 HIGH DATA BUS (+) HIGH DATA BUS (-) BLK WIRE BLK/WHT WIRE DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH) DIGITAL RADIO RECEIVER (ATTACHED TO LEFT WHEELHOUSE, UNDER LEFT TRIM PANEL) DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (BELOW BRAKE MASTER CYLINDER) ENGINE CONTROL MODULE (ECM) (MOUNTED ON TOP OF BATTERY COVER) EXCEPT 6 SPEED A/T HEATED SEAT CONTROL MODULE (UNDER RIGHT FRONT SEAT) HIGH DATA BUS (+) HIGH DATA BUS (-) HIGH SERIAL DATA BUS + HOT AT ALL TIMES HVAC CONTROL MODULE (AT CENTER OF DASH) HVAC/RFA FUSE 15 I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) INFLATABLE RESTRAINT PASSENGER (PPS) MODULE (UNDER PASSENGER SEAT) INSTRUMENT PANEL CLUSTER (IPC) LOW SERIAL DATA LT GRN/BLK WIRE POWER DISTRIBUTION SYSTEM RADIO REAR DIFFERENTIAL CLUTCH CONTROL MODULE (ON TOP REAR OF REAR DIFFERENTIAL) RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (ON RIGHT "C" PILLAR) ROLLOVER SENSOR (UNDER REAR CENTER OF CONSOLE, BEHIND SDM) SPLICE PACK STEERING ANGLE SENSOR TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TERMINATOR RESISTOR (BEHIND CENTER OF FUEL THEFT DETERRENT MODULE (TDM) (NEAR TOP OF STEERING COLUMN) TRANSMISSION CONTROL MODULE (TCM) (AT LEFT REAR CORNER OF ENGINE COMPT) W/ DIGITAL AUDIO SYSTEM
