Car Wiring Diagrams for Driver seat circuit for Suzuki XL7 I (1998-2009)

BLK WIRE DK BLU WIRE DK GRN WIRE DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT FRONT VERTICAL MOTOR (UNDER DRIVER SEAT) DRIVER SEAT HORIZONTAL MOTOR (UNDER DRIVER SEAT) DRIVER SEAT REAR VERTICAL MOTOR (UNDER DRIVER SEAT) FRONT VERTICAL DOWN FRONT VERTICAL UP HORIZONTAL FORWARD HORIZONTAL REARWARD HOT AT ALL TIMES I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LT BLU WIRE POWER SEAT CIRCUIT BREAKER REAR VERTICAL DOWN REAR VERTICAL UP RED WIRE RED/BLK WIRE YEL WIRE
