Automatic day/night mirror circuit for Suzuki XL7 I (1998-2009)
Automatic day/night mirror circuit
ACC VOL
AMBIENT LIGHT SENSOR
AUTOMATIC DAY/NIGHT MIRROR ELEMENT
BACKUP LP SPLY VOL
BLK WIRE
BODY CONTROL MODULE (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
IGN
INSIDE REARVIEW MIRROR
LO REF
LOGIC
LT GRN WIRE
MAGNETIC FIELD SENSOR
MESSAGE REQ
MIRROR DISPLAY
MIRROR SIG
RAP PCB RELAY
RAP RLY COIL SPLY VOL
S/ROOF FUSE 1
SENS SIG
TAN WIRE
YEL WIRE
