Instrument illumination circuit for Suzuki XL7 I (1998-2009)

BATT POS VOL BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) CHMSL/DIMR LAMP DIMMER SW SIG DIMMER SWITCH DK GRN WIRE DRIVER INFORMATION CENTER (DIC) SWITCH FOG LAMP SWITCH (IF EQUIPPED) FUSE 13 FUSE 22 GRY WIRE HAZARD SWITCH HOT AT ALL TIMES HVAC CONTROL MODULE (AT CENTER OF DASH) I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LED DIMMING SIG LEFT STEERING WHEEL CONTROL SWITCH ORG/WHT WIRE PANEL LMP SPLY VOL PPL/WHT WIRE RADIO REAR HVAC CONTROL RED/WHT WIRE RIGHT STEERING WHEEL CONTROL SWITCH STR/WHL/ ILLUM TRACTION CONTROL SWITCH (TCS)
