Suzuki XL7 I (1998-2009) wpr/ wshr fuse 36 Wiring diagram
This page shows the only wiring diagram for the component.wpr/ wshr fuse 36, which is found in the car Suzuki XL7 I (1998-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wpr/ wshr fuse 36 (1 of 1)
A/C CLUTCH FUSE 8
A/C COMP/ CLTCH RELAY 46
BANK 1 SENSOR 2
BANK 2 SENSOR 1
BANK 2 SENSOR 2
BLK WIRE
BODY CONTROL MODULE (BCM)
CAMSHAFT POSITION ACTUATOR (BANK 1 INTAKE)
CAMSHAFT POSITION ACTUATOR BANK 2 INTAKE
CRANK RELAY RELAY 55
DR/LCK FUSE 8
DRIVER FRONT PASSENGER CONSOLE CONSOLE WINDOW WINDOW SWITCH SWITCH
DRIVER UNLOCK PCB RELAY
DRL PCB RELAY
EMM DEV 2 FUSE 20 EMM DEV 1 FUSE 17 FAN 2 RELAY 61
EVAPORATIVE EMISSIONS (EVAP) CANISTER PURGE SOLENOID
FAN 1 FAN 3 RELAY 56 RELAY 60
FAN 1 FUSE 2 FAN 2 FUSE 1
FOG LAMP PCB RELAY HORN PCB RELAY
FROM BATT MAIN 3 FUSE 3 (DIAGRAM 1 OF 3)
FROM EVEN COILS INJ FUSE 18 (DIAGRAM 2 OF 3)
FROM RIGHT TRLR STOP/TURN RELAY 58 (DIAGRAM 3 OF 3)
FROM UNDERHOOD FUSE BLOCK (DIAGRAM 1 OF 3)
FRT, REAR WSHR FUSE 45
FUEL PUMP FUSE 39
FUEL PUMP RELAY 62
HEATED OXYGEN SENSOR
HIGH BEAM PCB RELAY
INFRARED TRANSMITTER MODULE (W/ DVD)
INSIDE REARVIEW MIRROR (ISRVM)
LEFT TRLR STOP/ TURN RIGHT TRLR STOP/ TURN
LOCK PCB RELAY
LOW BEAM PCB RELAY
PARK LAMP PCB RELAY
PCB RELAY
PNK PNK WIRE
PNK WIRE
PNK/BLK WIRE
POWER WINDOW CIRCUIT BREAKER
RAP PCB RELAY
REAR WINDOW WIPER MOTOR
RED WIRE
RELAY 59 RELAY 58
RR WASH PCB RELAY
RR WPR FUSE 3
RSE/KEY CAPTR FUSE 2
S/ROOF FUSE 1
STOP LAMP
STRTR FUSE 15
SUNROOF CONTROL MODULE
TAN WIRE
TO FUEL PUMP FUSE 39 (DIAGRAM 3 OF 3)
UNLOCK PCB RELAY
W/ ELECTROCHROMIC INSIDE REARVIEW MIRROR
W/ POWER SLIDING SUNROOF
WHT WIRE
WIPER HIGH PCB RELAY FRT WASHER PCB RELAY
WIPER PCB RELAY
WPR/ WSHR FUSE 36
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> WPR/ WSHR FUSE 36
