Suzuki XL7 I (1998-2009) wheel control switch Wiring diagram
This page shows the only wiring diagram for the component.wheel control switch, which is found in the car Suzuki XL7 I (1998-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wheel control switch (1 of 1)
ACCELERATOR PEDAL POSITION (APP) SENSOR (ON ACCELERATOR PEDAL LINKAGE ARM)
BATT POS VOLT STOP LP SW SIG
BATT POSITIVE VOLTAGE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
BRAKE PEDAL POSITION SENSOR (ON BRAKE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE
CRUISE CTRL IND DIMMING SIG
CRUISE CTRL SW SIG
CRUISE IND
DK BLU WIRE
DK GRN WIRE
ECM BAT FUSE 33
ENGINE CONTROL MODULE (ECM) (MOUNTED ON TOP OF BATTERY COVER)
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGN MAIN RELAY 31 ENERGIZED
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER
LEFT STEERING
LOGIC
LT BLU WIRE
NCA WIRE
ORG/BLK WIRE
PEDAL ASSEMBLY)
PNK WIRE
PPL
PPL STEERING WHEEL CTRL SPLY VOLT
RED/WHT WIRE
RVC FUSE 42
SENS SIG REF 5-VOLT REF
SET- RES+
SIR DISPLAY FUSE 25
SOUND SYSTEMS
STOP LP SW SIG
TAN WIRE
TAN/BLK WIRE
THROTTLE ACTUATOR CONTROL (TAC) MODULE (ATTACHED TO THROTTLE BODY)
TRANSMISSIONS PPL SYSTEM
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
WHEEL CONTROL SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit -> WHEEL CONTROL SWITCH
