Suzuki XL7 I (1998-2009) vanity mirror map lamp Wiring diagram
This page shows the only wiring diagram for the component.vanity mirror map lamp, which is found in the car Suzuki XL7 I (1998-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vanity mirror map lamp (1 of 1)
BATT POS VOL
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
CENTER DOME LAMP
COURTESY LMP SPLY VOL
COURTESY/MAP LAMP
DK BLU/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
INT LTS FUSE 23
LEFT
OFF
OFF DOOR ON
ON DOOR
ORG/ WIRE
REAR DOME LAMP
RED WIRE
RED/WHT WIRE
RIGHT
VANITY MIRROR DOME LAMP SWITCH
VANITY MIRROR MAP LAMP
VISOR
WHT WIRE
Go to component -> Courtesy lamps circuit -> VANITY MIRROR MAP LAMP
