Suzuki XL7 I (1998-2009) sunroof sw sig low ref sunroof sw open sunroof sw vent sunroof limit sw Wiring diagram
This page shows the only wiring diagram for the component.sunroof sw sig low ref sunroof sw open sunroof sw vent sunroof limit sw, which is found in the car Suzuki XL7 I (1998-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunroof sw sig low ref sunroof sw open sunroof sw vent sunroof limit sw (1 of 1)
1 2 3 4 5 6 7 8 LOW REF
ACC VOLT LOW REF SUNROOF MTR GND
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
BRN WIRE
CLOSE
DK BLU WIRE
DK GRN WIRE
EXPRESS (CLOSES W/SECOND DETENT)
GRN WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
LIMIT SWITCH
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
RAP PCB RELAY
RAP RLY SPLY
RED WIRE
S/ROOF FUSE 1
SLIDE VENT
SUNROOF CONTROL MODULE (RIGHT REAR OF SUNROOF MODULE ASSEMBLY)
SUNROOF SW SIG LOW REF SUNROOF SW OPEN SUNROOF SW VENT SUNROOF LIMIT SW
SUNROOF SWITCH
TAN WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> SUNROOF SW SIG LOW REF SUNROOF SW OPEN SUNROOF SW VENT SUNROOF LIMIT SW
