Suzuki XL7 I (1998-2009) ppl hdlp dim sw hi beam sig Wiring diagram

AMBIENT LIGHT SENSOR (UPPER LEFT DASH TRIM PANEL) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) BRN WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRL 2 FUSE 10 DRL AMBIENT LIGHT SENS SIG DRL FUSE 52 DRL PCB RELAY FOG LAMP FUSE 53 FOG LAMP IND DRL IND FOG LAMP PCB RELAY FOG LAMP RLY CTRL FOG LAMP SWITCH FR FOG LAMP SW SIG FTP FTP SW SIG GRY WIRE HDLP HI BEAM RLY CTRL HDLP LOW BEAM RLY CTRL HDLP SW HDLPS OFF SIG HDLP SW ON SIG HIGH BEAM PCB RELAY HIGH LOW HIGH LOW FTP HOT AT ALL TIMES HOT W/ IGN MAIN RELAY 31 ENERGIZED I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) INSTRUMENT PANEL CLUSTER (IPC) INTERIOR LIGHTS SYSTEM PPL LEFT FOG LAMP RIGHT FOG LAMP LEFT HEADLAMP LH HI BEAM FUSE 29 LH LOW BEAM FUSE 9 LOGIC LOW BEAM PCB RELAY LOW SPD GMLAN SER DATA LT GRN WIRE LT GRN/BLK WIRE OFF AUTO ORG/ WIRE PARK HEAD LIGHT CONTROL SWITCH PNK WIRE PNK/WHT WIRE PPL PPL DRL RLY CTRL PPL HDLP DIM SW HI BEAM SIG PPL PNK WIRE PPL PPL RH HI BEAM FUSE 11 RH LOW BEAM FUSE 28 RIGHT HEADLAMP SIR DISPLAY FUSE 25 TAN WIRE TAN/WHT WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE
