Suzuki XL7 I (1998-2009) mirror sig Wiring diagram
This page shows the only wiring diagram for the component.mirror sig, which is found in the car Suzuki XL7 I (1998-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror sig (1 of 1)
ACC VOL
AMBIENT LIGHT SENSOR
AUTOMATIC DAY/NIGHT MIRROR ELEMENT
BACKUP LP SPLY VOL
BLK WIRE
BODY CONTROL MODULE (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
IGN
INSIDE REARVIEW MIRROR
LO REF
LOGIC
LT GRN WIRE
MAGNETIC FIELD SENSOR
MESSAGE REQ
MIRROR DISPLAY
MIRROR SIG
RAP PCB RELAY
RAP RLY COIL SPLY VOL
S/ROOF FUSE 1
SENS SIG
TAN WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit -> MIRROR SIG
