Suzuki XL7 I (1998-2009) low heat indicator Wiring diagram

1 2 3 4 5 6 7 8 BATT POS VOL GND BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER BACK HEATED SEAT ELEMENT DRIVER CUSHION HEATED SEAT ELEMENT (IN DRIVER SEAT CUSHION) DRIVER HEATED SEAT SWITCH DRV HEATED SEAT NTC SIG DRV HEATED SEAT SPLY VOL FRONT PASSENGER BACK HEATED SEAT ELEMENT (IN FRONT PASSENGER SEAT BACK) FRONT PASSENGER CUSHION HEATED SEAT ELEMENT (IN FRONT PASSENGER SEAT CUSHION) FRONT PASSENGER HEATED SEAT SWITCH GRY WIRE HEATED SEAT CONTROL MODULE (UNDER RIGHT FRONT SEAT) HIGH HEAT INDICATOR HOT AT ALL TIMES HTD SEATS FUSE 6 HVAC CONTROL MODULE (AT CENTER OF DASH) I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LO REF LO SPD GMLAN LOGIC LOW HEAT INDICATOR LOW REF LOW SPEED GMLAN SERIAL DATA LT BLU WIRE ORG/ WIRE PNK TEMP SENS SIG WIRE PNK WIRE PPL PPL LO REF RED/WHT WIRE TAN WIRE YEL WIRE YEL/BLK WIRE
