Suzuki XL7 I (1998-2009) hot w/ park lamp pcb relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ park lamp pcb relay energized, which is found in the car Suzuki XL7 I (1998-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ park lamp pcb relay energized (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
BRN WIRE
DK GRN WIRE
HOT AT ALL TIMES
HOT W/ PARK LAMP PCB RELAY ENERGIZED
LT TRLR STOP/TRN FUSE 37
LT TRLR STOP/TRN RELAY 59
LT TRLR STOP/TURN RELAY CTRL
ORG/ WIRE
PRK/LP TRLR FUSE 35
RT TRLR STOP/TRN FUSE 43
RT TRLR STOP/TRN RELAY 58
RT TRLR STOP/TURN RELAY CTRL
TRAILER CONNECTOR ADAPTOR (IN LEFT LUGGAGE COMPT, NEAR SPARE TIRE)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Trailer tow circuit -> HOT W/ PARK LAMP PCB RELAY ENERGIZED
