Suzuki XL7 I (1998-2009) front passenger console power window switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger console power window switch, which is found in the car Suzuki XL7 I (1998-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger console power window switch (1 of 1)
BATT MAIN 3 FUSE 30
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DOWN
DRIVER CONSOLE POWER WINDOW SWITCH
DRIVER WINDOW MOTOR (IN LEFT FRONT DOOR)
EXPRESS LOGIC
FRONT PASSENGER CONSOLE POWER WINDOW SWITCH
FRONT PASSENGER WINDOW MOTOR (IN RIGHT FRONT DOOR)
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
LEFT FRONT
LEFT REAR
LEFT REAR WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR WINDOW SWITCH
LT BLU WIRE
LT GRN WIRE
OF ENGINE COMPARTMENT)
POWER WINDOW CIRCUIT BREAKER
PPL
RAP PCB RELAY
REAR WINDOW LOCKOUT SWITCH
RED WIRE
RIGHT FRONT
RIGHT REAR
RIGHT REAR WINDOW MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR WINDOW SWITCH
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE
YEL WIRE
Go to component -> Power windows circuit -> FRONT PASSENGER CONSOLE POWER WINDOW SWITCH
