Suzuki XL7 I (1998-2009) 2 59 28 gmlan serial data left seat belt sw seat pos sens lo Wiring diagram

2 59 28 GMLAN SERIAL DATA LEFT SEAT BELT SW SEAT POS SENS LO AJAR SW SIG AUTO OFF BATT POS VOLT BCM FUSE 20 BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER OF DASH, BEHIND HVAC CONTROL MODULE) BRN/WHT WIRE DK GRN WIRE DRIVER DOOR LATCH DRIVER SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE) FRONT PASSENGER DOOR LATCH GRY/BLK WIRE HEAD HOT AT ALL TIMES I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) IGN SW FUSE 19 IGNITION SWITCH INSTRUMENT PANEL CLUSTER (IPC) KEY IN IGN SW SIG KEY-IN IGNITION SWITCH LEFT REAR DOOR LATCH LF DR AJAR SW SIG LIFTGATE RELEASE ACTUATOR LOGIC ORG/BLK WIRE PARK PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER) PNK WIRE PNK/BLK WIRE PRK BRK SW SIG PRK LMP SW ON SIG RED/WHT WIRE RF DR AJAR SW SIG RIGHT REAR DOOR LATCH SEAT BELT IND SERIAL DATA SOUND SYSTEMS SUPPLEMENTAL RESTRAINTS SYSTEM PNK WIRE TAN/WHT WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH WHT WIRE WIPER/ WASHER SYSTEM
