Wiring diagram engine performance 1.6ls, m/t & 3 speed a/t (2 of 3) for Suzuki X-90 I (1995-2000)

A/T BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN/RED WIRE BRN/YEL WIRE CLUTCH PEDAL POSITION SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL) DIAGNOSIS COUPLER (ON RIGHT INNER FENDER PANEL, BEHIND HEADLIGHT) ENGINE COOLANT TEMPERATURE EVAP CANISTER AIR VENT CONTROL VALVE (ON RIGHT INNER FENDER PANEL) FUEL PUMP (IN FUEL TANK) GRN/RED WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES IGNITION SWITCH INTAKE AIR TEMPERATURE (IAT) SENSOR (ON AIR CLEANER) ASSEMBLY) J/C LOCK M/T MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (ON RIGHT SIDE OF FIREWALL) MASS AIRFLOW SENSOR PNK 19 20 21 WIRE PNK WIRE PNK/BLK WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM TANK PRESSURE SENSOR (UNDERSIDE OF VEHICLE, NEAR FUEL TANK) TCC SOLENOID VALVE (ON (TRANSMISSION HOUSING) TRANSMISSION ASSEMBLY TRANSMISSION RANGE SWITCH (CLOSED IN P OR N) (ON VIO WIRE VIO/YEL WIRE WHT WIRE WHT/YEL WIRE YEL (OR RED/BLU) WIRE
