Suzuki X-90 I (1995-2000) driver's door lock main switch Wiring diagram
This page shows the only wiring diagram for the component.driver's door lock main switch, which is found in the car Suzuki X-90 I (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door lock main switch (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
DOOR LOCK CONTROLLER (BEHIND DASH, LEFT OF STEERING COLUMN)
DRIVER'S DOOR LOCK MAIN SWITCH
DRIVER'S DOOR MOTOR, SWITCH
FUSE 14
FUSE BLOCK (PASSENGER COMPARTMENT) (BEHIND DASH, UNDER STEERING COLUMN)
HOT AT ALL TIMES
J/C
NCA WIRE
OPEN CONNECTOR (PARTIAL) (RIGHT SIDE OF DASH) PNK WIRE
PASSENGER'S DOOR MOTOR, SWITCH
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
RED WIRE
