Warning systems circuit for Suzuki Vitara I (1988-2006)
Warning systems circuit
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
COMBINATION METER
DOME FUSE
GRY/RED WIRE
HEAD- LIGHT RELAY 2
HOT AT ALL TIMES
HOT IN ON OR START
IG METER FUSE
IGNITION SWITCH
KEY REMINDER SWITCH
LEFT FRONT DOOR SWITCH
RED/YEL WIRE
SEAT BELT IND
SEAT BELT SWITCH (IN DRIVER SEAT BELT BUCKLE)
TAIL FUSE
UNDERDASH FUSE/ RELAY BOX (AT LOWER LEFT SIDE OF DASH)
WARNING BUZZER
WHT WIRE
