Car Wiring Diagrams for Supplemental restraints circuit for Suzuki Vitara I (1988-2006)

A/B SDM (AIR BAG SENSING, DIAGNOSTIC MODULE) (AT LOWER CENTER OF DASH) AIR BAG INDICATOR BLK WIRE BLU WIRE BLU/RED WIRE COMBINATION METER CONNECTION DETECTION PIN CONTACT COIL DIAGNOSIS CONNECTOR (AIR BAG) (BEHIND LOWER LEFT SIDE OF DASH) 1 2 3 4 PPL DRIVER INFLATOR FUSE 28 GRN WIRE GRN/RED WIRE GRY WIRE HOT IN ON OR START IG METER FUSE 21 NCA WIRE PASSENGER INFLATOR PPL PPL/GRN WIRE RED WIRE SEAT BELT INDICATOR SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE) SHORTING BAR SUPPLEMENTAL FUSE BOX 1 UNDERDASH FUSE/RELAY BOX (AT LOWER LEFT SIDE OF DASH) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE
