Radio circuit for Suzuki Vitara I (1988-2006)
Radio circuit
ANTENNA
BLK WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CIGAR/RADIO FUSE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES DOME FUSE
HOT IN ACC OR ON
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
RADIO
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
UNDERDASH FUSE/RELAY BOX (AT LOWER LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
