Car Wiring Diagrams for Headlights circuit for Suzuki Vitara I (1988-2006)

AUTOLIGHT CONTROLLER (ON TOP RIGHT SIDE OF DASH) BLK WIRE BLK/WHT WIRE BLU WIRE BRAKE IND CHARGE IND COMBINATION METER COMBINATION SWITCH DIMMER/PASSING SWITCH DIODE 1 (RIGHT END OF DASH) GENERATOR H/L, L FUSE H/L, R FUSE HEADLIGHT RELAY 1 (IN UNDERDASH FUSE/RELAY BOX) HI-BEAM IND HOT AT ALL TIMES HOT IN ON HOT IN ON OR START IG METER FUSE KEYLESS CONTROLLER (IF EQUIPPED) (AT LOWER LEFT SIDE OF DASH) LEFT HEADLIGHT LIGHT SWITCH LO LO PASS HI HI PASS PARKING BRAKE SWITCH (AT CENTER FLOOR CONSOLE) PNK WIRE PNK/BLU WIRE PPL PPL/WHT WIRE REAR DEFG FUSE RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT HEADLIGHT TAIL TAIL HEAD HEAD OFF OFF UNDERDASH FUSE/RELAY BOX (AT LOWER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (AT RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
