Car Wiring Diagrams for Defoggers circuit for Suzuki Vitara I (1988-2006)

BLK WIRE BLK/RED WIRE ENGINE CONTROLS SYSTEM GRN WIRE HOT IN ON REAR DEFG FUSE ILLUMINATION ON IND. REAR DEFOGGER REAR DEFOGGER SWITCH REAR DEFOGGER TIMER (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BLU WIRE UNDERDASH FUSE/RELAY BOX (AT LOWER LEFT SIDE OF DASH) YEL WIRE YEL/GRN WIRE
