Suzuki Vitara I (1988-2006) left side marker light left front clear- ance light Wiring diagram
This page shows the only wiring diagram for the component.left side marker light left front clear- ance light, which is found in the car Suzuki Vitara I (1988-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side marker light left front clear- ance light (1 of 1)
A/T, M/T: W/ CRUISE CONTROL
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BRAKE LIGHT SWITCH (BEHIND LEFT SIDE OF DASH)
BRAKE/
BRAKE/ TURN
COMBI- NATION SWITCH
COMBINATION METER
COMBINATION SWITCH
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD FUSE
HAZARD SWITCH
HEAD OFF TAIL LIGHTING SWITCH
HEADLIGHT RELAY 2
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUM
LEFT FRONT TURN SIGNAL LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LIGHT
LEFT SIDE MARKER LIGHT LEFT FRONT CLEAR- ANCE LIGHT
LEFT TURN IND
M/T: W/O CRUISE CONTROL
OFF ON OFF ON OFF ON
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT CLEAR- ANCE LIGHT
RIGHT FRONT TURN SIGNAL LIGHT RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TURN IND
STOP/HORN FUSE
TAIL
TAIL FUSE
TRAILER CONNECTOR (LEFT REAR OF VEHICLE)
TURN
TURN BACK FUSE
TURN SIGNAL RELAY
TURN SIGNAL SWITCH
UNDERDASH FUSE/RELAY BOX (AT LOWER LEFT SIDE OF DASH)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit -> LEFT SIDE MARKER LIGHT LEFT FRONT CLEAR- ANCE LIGHT
