Power top/sunroof circuit for Suzuki Verona I (2003-2006)
Power top/sunroof circuit
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE
ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT)
FUSE 11
FUSE 15
FUSE 29
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
I/P FUSE BLOCK (LEFT END OF DASH)
KEY REMINDER SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
SUN ROOF MODULE (FRONT CENTER OF HEADLINER)
SUN ROOF MOTOR (AT CENTER FRONT OF ROOF)
SUNROOF SWITCH
TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) (A/T)
VEHICLE SPEED SENSOR (M/T)
WHT WIRE
YEL WIRE
