Power door locks circuit for Suzuki Verona I (2003-2006)
Power door locks circuit
ANTI-THEFT SYSTEM
BLK WIRE
BRN WIRE
ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT)
FUSE 11
FUSE 5
FUSE 6
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON, RUN
I/P FUSE BLOCK (LEFT END OF DASH)
INTELLIGENT SWITCHING UNIT (LOWER LEFT SIDE OF DASH)
LEFT CENTRAL DOOR LOCK UNIT
LEFT FRONT DOOR ACTUATOR
LEFT REAR DOOR ACTUATOR
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN/WHT WIRE
PNK WIRE
RED WIRE
RIGHT CENTRAL DOOR LOCK UNIT
RIGHT FRONT DOOR ACTUATOR
RIGHT REAR DOOR ACTUATOR
