Exterior lamps circuit for Suzuki Verona I (2003-2006)

ANTI-LOCK BRAKES SYSTEM BLK WIRE BLU WIRE BLU/WHT WIRE BRAKE SWITCH (LOWER LEFT SIDE OF DASH) BRN WIRE BRN/WHT WIRE CENTER HIGH MOUNT STOP LAMP ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT) FUSE 11 FUSE 19 FUSE 21 FUSE 22 FUSE 5 FUSE 6 GRN WIRE HAZARD SWITCH HEADLIGHTS SYSTEM (DRL RELAY) HOT AT ALL TIMES HOT IN RUN HOT IN RUN, START I/P FUSE BLOCK (LEFT END OF DASH) ILLUMINATION RELAY INSTRUMENT CLUSTER INTELLIGENT SWITCHING UNIT (LOWER LEFT SIDE OF DASH) LEFT TURN LEFT TURN INDICATOR LIGHT SWITCH PARK HEAD OFF LT BLU WIRE LT BLU/WHT WIRE MI COM ODO SWITCH ORG/ WIRE PNK WIRE PPL RED WIRE RIGHT TURN RIGHT TURN INDICATOR TRANSMISSIONS SYSTEM TURN SIGNAL SWITCH VIO WIRE WHT WIRE

BLK WIRE BLU WIRE BRN/WHT WIRE LEFT FRONT PARKING LAMP LEFT FRONT TURN SIGNAL LAMP LEFT LICENSE PLATE LAMP LEFT SIDE TURN SIGNAL LAMP LEFT TAIL LAMP RIGHT SIDE TURN SIGNAL LAMP LT BLU WIRE LT BLU/WHT WIRE PARK RIGHT FRONT PARKING LAMP RIGHT FRONT TURN SIGNAL LAMP RIGHT LICENSE PLATE LAMP RIGHT TAIL LAMP STOP TURN VIO WIRE WHT WIRE
