Suzuki Verona I (2003-2006) right sun visor switch Wiring diagram
This page shows the only wiring diagram for the component.right sun visor switch, which is found in the car Suzuki Verona I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right sun visor switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER ROOM LAMP
ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT)
FUSE 11
FUSE 5
FUSE 6
GLOVE BOX LAMP)
GLOVE BOX LAMP/ SWITCH
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, START
I/P FUSE BLOCK (LEFT END OF DASH) FUSE 13
INSTRUMENT CLUSTER SYSTEM
INTELLIGENT SWITCHING UNIT (LOWER LEFT SIDE OF DASH)
INTERIOR COURTESY LAMP
KEY ILLUMINATION LAMP
KEY REMINDER SWITCH
LEFT FRONT DOOR CONTACT SWITCH
LEFT REAR DOOR CONTACT SWITCH
LEFT STEP LAMP
LEFT SUN VISOR SWITCH
LEFT VANITY MIRROR LAMP
OFF
OFF ON DR
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
PPL
RED WIRE
RIGHT FRONT DOOR CONTACT SWITCH
RIGHT REAR DOOR CONTACT SWITCH
RIGHT SUN VISOR SWITCH
RIGHT VANITY MIRROR LAMP
TRUNK LATCH ASSEMBLY
TRUNK OPEN LAMP
WHT WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit -> RIGHT SUN VISOR SWITCH
