Suzuki Verona I (2003-2006) intelligent switch unit Wiring diagram
This page shows the only wiring diagram for the component.intelligent switch unit, which is found in the car Suzuki Verona I (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intelligent switch unit (1 of 1)
AIR CONDI- TIONING SYSTEM
AIR CONDI- TIONING,
AIR CONDITIONING SYSTEM ANTI-LOCK BRAKE SYSTEM, A/D CONVERTER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL, SOUND SYSTEMS
DEFOGGER SYSTEM
ELECTRONIC POWER STEERING SYSTEMS
ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT)
FOG RELAY
FROM ENGINE FUSE BLOCK (DIAGRAM 1 OF 3)
FUSE 1
FUSE 11
FUSE 14
FUSE 18
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 25
FUSE 26
FUSE 5
FUSE 6
FUSE 7
FUSE 8
HEAD- LIGHTS SYSTEM
HEADLIGHTS SYSTEM
HORN RELAY
I/P FUSE BLOCK (LEFT END OF DASH)
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM
INTELLIGENT SWITCH UNIT
INTERIOR LIGHTS SYSTEM,
MIRRORS SYSTEM
OFF
ORG/ WIRE
PNK WIRE
POWER WINDOW RELAY
POWER WINDOWS SYSTEM
PPL
RED WIRE
RUN WIRE
SHIFT INTERLOCK SYSTEM
STARTING/ CHARGING SYSTEM
TO ENGINE FUSE BLOCK (DIAGRAM 1 OF 3)
TO I/P FUSE BLOCK (DIAGRAM 3 OF 3)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> INTELLIGENT SWITCH UNIT
