Suzuki Verona I (2003-2006) acp sensor Wiring diagrams
This page contains all the electrical diagrams for the component. acp sensor, in which he is found in the car Suzuki Verona I (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram acp sensor (1 of 3)
A/C COMPRESSOR RELAY (DIAGRAM 1 OF 2)
ACP SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COOLING FAN (LOW)
COOLING FAN AUX (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN CONTROL RELAY
COOLING FAN HIGH RELAY
COOLING FAN MAIN (BEHIND LEFT SIDE OF RADIATOR)
ENGINE CONTROL MODULE (LEFT FRONT OF ENG COMPT)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENG)
ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT)
FUSE 27
FUSE 4
FUSE 6
FUSE 7
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ON
HOT W/ ENGINE MAIN RELAY ENERGIZED
I/P FUSE BLOCK (LEFT END OF DASH)
LT BLU/WHT WIRE
RED/BLK WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> ACP SENSOR
Wiring diagram acp sensor (2 of 3)
102 93 36 71 65 48 13 RELAY SW RELAY SW SENS GND ECT SIG SENS GND
A/C COMPRESSOR RELAY
ACP SENSOR
ACP SIG
BLK WIRE
BLK/WHT WIRE
BLU WIRE
COOLING FAN (LOW)
COOLING FAN AUX (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN CONTROL RELAY
COOLING FAN HIGH RELAY
COOLING FAN MAIN (BEHIND LEFT SIDE OF RADIATOR)
ENGINE CONTROL MODULE (LEFT FRONT OF ENG COMPT)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENG)
ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT)
FUSE 27
FUSE 4
FUSE 7
GRN WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/ ENGINE MAIN RELAY ENERGIZED
LT BLU/WHT WIRE
RED/BLK WIRE
RELAY
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> ACP SENSOR
Wiring diagram acp sensor (3 of 3)
102 93 36 71 65 48 13 25 106 RELAY SW RELAY SW SENS GND ECT SIG SENS GND
A/C COMPRESSOR RELAY (DIAGRAM 1 OF 2)
ACP SENSOR
ACP SIG ACP SIG ACP SIG
BLK WIRE
BLK/WHT WIRE
BLU WIRE
COOLING FAN (LOW)
COOLING FAN AUX (BEHIND RIGHT SIDE OF RADIATOR)
COOLING FAN CONTROL RELAY
COOLING FAN HIGH RELAY
COOLING FAN MAIN (BEHIND LEFT SIDE OF RADIATOR)
ENGINE CONTROL MODULE (LEFT FRONT OF ENG COMPT)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (FRONT OF ENG)
ENGINE FUSE BLOCK (LEFT FRONT OF ENG COMPT)
FUSE 27
FUSE 4
FUSE 7
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/ ENGINE MAIN RELAY ENERGIZED
LT BLU/WHT WIRE
RED/BLK WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> ACP SENSOR
