Computer data lines circuit for Suzuki SX4 I facelift (2009-2014)
Computer data lines circuit
A/B SDM (10 CH) (CENTER OF VEHICLE FLOOR)
ABS CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
COMBINATION METER
CVT CONTROL MODULE
DLC (DATA LINK CONNECTOR) (BELOW LEFT SIDE OF DASH)
DOME FUSE
ENGINE CONTROL MODULE (ECM) (AT SIDE OF BATTERY)
ESP CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
HOT AT ALL TIMES
HVAC CONTROL MODULE (CENTER
ID CONTROL MODULE (IF EQUIPPED)
JUNCTION BLOCK ASSEMBLY (LEFT SIDE OF DASH)
KEYLESS START CONTROL MODULE
MODULE (CENTER OF DASH)
OF DASH)
RED WIRE
STEERING ANGLE SENSOR (W/ ESP) (IN STEERING COLUMN ASSEMBLY)
WHT WIRE
WHT/RED WIRE
YAW RATE/G SENSOR (W/ ESP)
