Suzuki SX4 I facelift (2009-2014) turn signal switch off 13 10 tail Wiring diagram
This page shows the only wiring diagram for the component.turn signal switch off 13 10 tail, which is found in the car Suzuki SX4 I facelift (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn signal switch off 13 10 tail (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRAKE LIGHT SWITCH
BRAKE/
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
CPU CAN
DOME FUSE
FLASHER RELAY
GRN WIRE
GRN/ WHT WIRE
GRN/RED WIRE
GRN/WHT WIRE
HATCHBACK
HATCHBACK SEDAN
HAZARD SWITCH
HEAD LIGHT SWITCH
HIGH-MOUNTED BRAKE LIGHT
HORN-HAZ FUSE
HOT AT ALL TIMES
HOT IN ON OR START
J/C
JUNCTION BLOCK ASSEMBLY (LEFT SIDE OF DASH)
LEFT FRONT POSITION LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR COMBINATION LIGHT
LEFT SIDE MARKER LIGHT
LEFT TURN IND
LICENSE PLATE LIGHT 1
LICENSE PLATE LIGHT 2
LIGHT
LOW POSITION LIGHT IND
LP-L
LP-R
MTR FUSE
ON BACK WINDOW
ON TRUNK
RED WIRE
RED YEL/ WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT POSITION LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TURN IND
SEDAN
SEDAN HATCHBACK
SHIFT LOCK RELAY (AT SIDE OF BATTERY)
SIGNAL
SIGNAL TURN
STOP FUSE
SW-L
SW-R
TAIL
TAIL FUSE
TAIL LIGHT RELAY
TURN
TURN SIGNAL SWITCH OFF 13 10 TAIL
WHT WIRE
WHT/RED WIRE
Go to component -> Exterior lamps circuit -> TURN SIGNAL SWITCH OFF 13 10 TAIL
