Suzuki SX4 I facelift (2009-2014) engine control module (ecm) (at side wiring diagram
This page shows the only wiring diagram for the component.engine control module (ecm) (at side, which is found in the car Suzuki SX4 I facelift (2009-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
engine control module (ecm) (at side wiring diagram (1 of 1)
ABS CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
ABS FUSE MTR FUSE
ABS IND.
ABS MOT FUSE
ABS SOL FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRAKE IND
BRAKE LIGHT SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM) (AT SIDE
G SENSOR
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INDIVIDUAL CIRCUIT FUSE BOX 1
J/C
JUNCTION BLOCK ASSEMBLY (LEFT SIDE
LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL HUB ASSEMBLY)
LT GRN WIRE
LT GRN/BLK WIRE
OF BATTERY)
OF DASH)
RED WIRE
RED/BLK WIRE
RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL HUB ASSEMBLY)
STOP FUSE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, without esp -> ENGINE CONTROL MODULE (ECM) (AT SIDE
