Tire pressure monitoring circuit for Suzuki SX4 I (2006-2009)
Tire pressure monitoring circuit
ABS/ESP CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
AT HAND BRAKE ASSEMBLY)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOME FUSE
DRIVER SIDE DOOR SWITCH
ENGINE CONTROL MODULE (ECM) (AT SIDE OF BATTERY)
FUSE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IG-COIL FUSE
J/B ASSEMBLY (LEFT SIDE OF DASH)
J/C
LT GRN WIRE
MICRO CONTROLLER
MTR FUSE
ORG/ WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
STEPPER MOTOR, LED OUTPUT DRIVER
TIRE PRESSURE IND
TPMS RECEIVER (UNDER CENTER CONSOLE,
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
