Multi-information system circuit, without illumination cancel switch for Suzuki SX4 I (2006-2009)
Multi-information system circuit, without illumination cancel switch
ACC 2 FUSE
AMBIENT TEMPERATURE SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
DOME FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
J/C
JUNCTION BLOCK ASSEMBLY (LEFT SIDE OF DASH)
MULTI-INFORMATION DISPLAY
ORG/ WIRE
RED WIRE
RED/YEL WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
